Multi-Impedance Reactive Load box & Active Attenuator

Introducing Torpedo Reload II. The latest installment in Two notes' class-leading reactive load solution legacy marking the definitive watershed in contemporary backline control. Featuring twin-channel operation, selectable multi-impedance compatibility and true continuous attenuation, Reload II is our most advanced Load Box to date. Its mission is simple: unleash the power of any amplifier or line-level source without compromise.

Armed with a ground-up rework of our defining reactive load for a Celestion® Approved Load Response, the match is set to drive any amp's power-stage (rated up-to 200W RMS) to perfection, retaining all the sonic integrity your performance demands. Scalable from a whisper to a full-throttle onslaught, Reload II's ultra-transparent dual-mono 215W (per channel) amplifier/attenuator and paired speaker outputs preserve every facet of your tone. Add a Stereo FX Loop, twin DI outputs and GENOME Reload II Edition (software download) into the mix and Reload MKII doesn't just enhance your rig, it redefines it.

Key Features:

• Twin-Channel Operation: Independent source selection per channel for versatile routing.
• Selectable Multi-Impedance Compatibility: Supports 4Ω, 8Ω, and 16Ω settings to match different amplifier outputs.
• Continuous Attenuation: Adjust your amplifier's output from full volume to complete silence while maintaining tonal integrity.
• Celestion® Approved Load Response: Industry-first reactive load design inspired by Celestion®'s iconic drivers.
• 215W Per Channel Power Amplifier: Delivers ample power to drive your speaker cabinets.
• Stereo FX Loop: Integrate external effects with series/parallel routing options and footswitch activation.
• Dual Line Outputs: Seamless integration with audio interfaces, cab sims, and other recording or live sound equipment.
• GENOME Reload II Edition Software: Included software for studio-grade cabinet simulation.

Technical Specifications:

• Speaker Input: 6.35mm (1/4") unbalanced jack; max input voltage: 140V AC (45dBu); max security load: 270Ω / 20W.
• Load Input Level: Adjustable via potentiometer with continuous attenuation (-inf) to continuous amplification (+20dB).
• Speaker Outputs: Two 6.35mm (1/4”) unbalanced jacks; min load: 3.5Ω; max output power per channel: 215W RMS @ 4Ω, 120W RMS @ 8Ω, 50W RMS @ 16Ω.
• Line Inputs: Dual-mono 6.35mm (1/4”) balanced jacks; impedance: 300Ω; gain: +4 to -inf dB; max output level: 20dBu; frequency response: 20Hz to 20kHz.
• FX Loop: Dual-mono with independent channel controls; compatibility with +4dBu and -10dBV devices; dry/wet potentiometer with on/off switch; footswitch activation via 6.35mm (1/4”) jack.
• Load Box: Reactive load with switchable 4Ω, 8Ω, and 16Ω impedance; maximum admissible power: 200W RMS; peak power: 250W.
