MXR M133 Micro Amp

MXR® MICRO AMP
The Micro Amp allows you to boost your signal with a preset amount of gain up to +26dB.

This pedal can be powered by a 9-volt battery, a Dunlop ECB003 9-volt adapter, or the DC Brick™, Iso-Brick™, and Mini Iso-Brick™ power supplies (not included).

Adding a preset amount of gain with just a single control, the Micro Amp is a great way to boost your signal for lead work or adjust between two different guitars with unmatched output (ie humbuckers to single-coils). It can also provide a permanent boost in a long effects chain where signal drop off is a problem.

SPECIFICATIONS

• Input Impedance 1 MΩ
• Output Impedance 470 Ω
• Maximum Output Level +6 dBV
• Noise Floor* -80 dBV
• Gain Control +0.5 dB to +26 dB
• Freq. Response 20 Hz to 20 kHz,
• +0 dB, -1.4 dB
• Bypass Hardwire
• Current Draw 2.5 mA
• Power Supply 9 volts DC
