Allpedal Devils Triad

Ordinarie pris 4 625 SEK Reapris 4 625 SEK
Nyhet
SKU: 12801 Barcode: 850037850662
Allpedal Devils Triad

THE DEVIL'S TRIAD™ - MADE IN USA - JEFF LOOMIS SIGNATURE GUITAR PEDAL

OVERDRIVE

  • Drive: Analog op-amp with Soft Clipping
  • 260K @ 1KhZ
  • Level: Off - 20db
  • Tone: 10db Boost @ 4KhZ | 15db cut @ 4KhZ
  • Gain: Increases Signal to the clipping LEDS to increase distortion.


BOOST

  • Boost: Analog op-amp
  • Measured input impedance: 325K @ 1KhZ
  • Boost: Unity - 20db

REVERB

  • Analog signal path with digital plate reverb emulator.
  • Level: Volume of wet signal, dry signal always unity level.
  • Tone: Attenuates highs from wet signal only.
  • Decay: Sets the level of wet signal feedback.


DELAY

  • Analog signal path with digital repeats.
  • Measured input impedance: 250K @ 1KhZ
  • Level: Volume of the repeats, dry signal always unity level.
  • Feedback: Number of repeats.
  • Delay: Time between repeats ~50ms minimum / ~500ms maximum.


TECHNICAL DETAILS

  • Size: 4.7" x 5.75" (121mm x 145mm)
  • Power: 9V Power Jack (No battery connector inside)
  • Power Draw: 160mA
  • True Bypass
